Mori Seiki NT5400 DGC/1800SZ 2007

MACHINE SPECIFICATIONS

• ATC Capacity:

  80

• Main Chuck Diameter:

  18"

• Max Main Spindle Speed:

  2,400 RPM

• Main chuck Hole Thru:

  4"

• Main Spindle Bore:

  4.5"

• Sub Chuck Diameter:

  18 "

• Max Sub Spindle Speed:

  2,400 RPM

• Sub Spindle Bore:

  4.5"

• Sub Chuck Hole Thru:

  4"

• Max Swing (inches):

  36.2 "

• Swing over cross slide:

  36.2 "

• Maximum Machining Diameter:

  36.2 "

• Maximum Machining Length:

  75.6 "

• Main Spindle Nose:

  A2-11

• Main Motor (HP):

  50/40 hp

• Sub Spindle Motor:

  50/40 hp

• X-Axis Travel:

  40.9"

• Y-Axis Travel:

  10"

• Z-Axis Travel:

  76.4"

• Live Tooling Max Speed:

  6,000 RPM

• Turret Capacity:

  10

• Live Tooling Motor:

  40/30 hp

• C-Axis Indexing Main Spindle:

  .001 °

• C-Axis Indexing Sub Spindle :

  .001 °

• Number of Jaws:

  3

• Spindle Taper:

  Capto C8

• Max Amperage:

  394

• Voltage:

  230/3/60
