Tarus DHDM 2018

Sold Image

5 Axis Machining Center Tarus DHDM 2018 1

5 Axis Machining Center Tarus DHDM 2018 2

5 Axis Machining Center Tarus DHDM 2018 3

5 Axis Machining Center Tarus DHDM 2018 4

5 Axis Machining Center Tarus DHDM 2018 5

5 Axis Machining Center Tarus DHDM 2018 6

5 Axis Machining Center Tarus DHDM 2018 7

5 Axis Machining Center Tarus DHDM 2018 8

5 Axis Machining Center Tarus DHDM 2018 9

5 Axis Machining Center Tarus DHDM 2018 10

5 Axis Machining Center Tarus DHDM 2018 11

5 Axis Machining Center Tarus DHDM 2018 12

5 Axis Machining Center Tarus DHDM 2018 13

5 Axis Machining Center Tarus DHDM 2018 14

5 Axis Machining Center Tarus DHDM 2018 15

5 Axis Machining Center Tarus DHDM 2018 16

5 Axis Machining Center Tarus DHDM 2018 17

5 Axis Machining Center Tarus DHDM 2018 18

5 Axis Machining Center Tarus DHDM 2018 19

5 Axis Machining Center Tarus DHDM 2018 20

5 Axis Machining Center Tarus DHDM 2018 21

5 Axis Machining Center Tarus DHDM 2018 22

5 Axis Machining Center Tarus DHDM 2018 23

5 Axis Machining Center Tarus DHDM 2018 24

5 Axis Machining Center Tarus DHDM 2018 25

5 Axis Machining Center Tarus DHDM 2018 26

Tarus DHDM 2018 28

Tarus DHDM 2018 2

Tarus DHDM 2018 2

Tarus DHDM 2018 2

Tarus DHDM 2018 2

Tarus DHDM 2018 3

Tarus DHDM 2018 4

Tarus DHDM 2018 5

Tarus DHDM 2018 6

Tarus DHDM 2018 7

Tarus DHDM 2018 8

Tarus DHDM 2018 9

Tarus DHDM 2018 10

Tarus DHDM 2018 11

Tarus DHDM 2018 12

Tarus DHDM 2018 13

THIS MACHINE HAS SOLD AND IS NO LONGER AVAILABLE. WE MIGHT STILL HAVE A SIMILIAR MODEL OR EXACT MATCH. BROWSE CURRENT INVENTORY OR CONTACT AN AGENT BELOW.

MAKE: Tarus
MODEL: DHDM
YEAR: 2018
TYPE: 5 Axis Machining Center
CONTROL: Heidenhein TNC 640
REF #: 3201751

MACHINE SPECIFICATIONS

X-Axis Travel:

135"
Y-Axis Travel:

62"
Z-Axis Travel:

48.5"
W-Axis Travel:

92” (Gundrill)
A axis (tilt):

+-15* Deg
Axis Rapid:

600 IPM
Rotary Table:

360 Deg Postioning
Rotary Table Weight Capacity:

65,000 Lbs
Rotary Table Size:

79” x 59”
Milling Spindle Power:

23 kW (47kw Max)
Milling Spindle Taper:

ISO#50
Milling Spindle Rpm:

0-3000 Rpm
Milling Spindle Torque:

220nm (500nm Max)
Gundrill Spindle Taper:

64 mm Collet Holder
Gundrill Spindle Power:

23 kw (47kW Max)
Gundrill Spindle Torque:

220 Nm (500 Nm Max)
Gundrill Spindle Speed:

0-3400 RPM
Gundrill Max Dia:

2"
BTA Max Dia:

1.5”in
Coolant System Type:

2 Eaton Piston Pumps
Coolant Pump A:

3-20 GPM
Coolant Pump B:

20 GPM
Coolant Pump Max Pressure:

1500 PSI / 40 GPM Flow
Coolant Tank Capacity:

750 Gal
Chiller Unit:

Cooled Drilling Coolant
Milling Tool Changer:

60 Tool Pods
Wireless Touch Probe:

Blum TC60
Tool And Drill Measuring:

Blum
Table Enclosure:

2 Sliding Doors And 2 Removable Front Doors
Power:

460 Volts /60 Cycle /55 Amp
Measuring System:

Heidenhein Scales
Servo Motors:

Liquid Cooled Bosh Motors
Servo Drives:

Heidenhain

MACHINE EQUIPPED WITH

Rotary Table
tool changer
gun drill attachment
built in 2018
