Nakamura Tome WT300 2013

MACHINE SPECIFICATIONS

• Max Turning Diameter:

  10.6 (270) in (mm)

• DRIVEN TOOL SPINDLE:

  7.5 HP

• Main Spindle:

  25 HP

• Number of Tool Stations:

  24

• Least input increment:

  1E-3 degree

• Right Spindle Nose:

  A2-6

• Right Spindle Speed:

  4500 rpm

• RIGHT SPINDLE:

  4500 rpm

• Left Spindle Nose:

  A2-8

• Left Spindle Speed:

  3500 / 2500 rpm

• Rapid Feed Z1/Z2:

  1063 (27) / 1063 (27) in/min (m/min)

• SLIDE TRAVEL B:

  33.5 (850) in (mm)

• Capacity:

  ø3.2 in ( 80) / ø4 (102) (op.) in (mm)

• Distance Between Spindles:

  43.3 (1100) / min 9.8 (250) in (mm)

• Max Turning Length:

  30.7 (780) in (mm)

• Bar Capacity:

  4 (102) (op.) in (mm)

• Chuck Size:

  8"

• SLIDE TRAVEL X1/X2:

  7.4 (188) / 7.7 (195) in (mm)

• Slide Travel Z1/Z2:

  30.7 (780) / 30.7 (780) in (mm)

• Slide Travel Y:

  ±2.4 (60) in (mm)

• Rapid Feed X1/X2:

  630 (16) / 630 (16) in/min (m/min)

• BAR CAPACITY L-SPINDLE:

  3.2 in (80 ) in (mm)

• BAR CAPACITY R-SPINDLE:

  2.6 (65) in (mm)

• LEFT HOLE THROUGH DRAW TUBE :

  3.2 (81) / 4 (103) in (mm)

• RIGHT HOLE THROUGH DRAW TUBE:

  2.5 (66) in (mm)

• ROTARY SYSTEM/NUMBER OF DRIVEN-TOOL STATIONS:

  24

• RIGHT SPINDLE SPEED RANGE:

  Stepless

• NUMBER OF ROTATION TOOL STATION:

  12×2

• SUB SPINDLE (OP.):

  25
