THIS MACHINE HAS SOLD AND IS NO LONGER AVAILABLE. WE MIGHT STILL HAVE A SIMILIAR MODEL OR EXACT MATCH. BROWSE CURRENT INVENTORY OR CONTACT AN AGENT BELOW.

  • MAKE: Fanuc

  • MODEL: Robodrill A-T21iFL

  • YEAR: 2008

  • TYPE: Drill and Tap

  • CONTROL: Fanuc 31i- Model A5

  • REF #: 3644229

MACHINE SPECIFICATIONS

  • X-Axis Travel:

    27.5"

  • Y-Axis Travel:

    15.74"

  • Z-Axis Travel:

    13"

  • B-Axis Travel:

    0 deg ~ +90 deg (Trunnion)

  • C-Axis Travel:

    +/- 360 deg (Trunnion)

  • Table Size:

    33.46" x 16.10"

  • Max Workpiece Weight:

    660 lbs

  • Spindle Motor:

    15 HP

  • Spindle Speed:

    10,000 RPM

  • Spindle Taper:

    BT-30

  • Tool Changer:

    21 ATC

  • Rapid Rate (X/Y/Z):

    2,125 IPM

  • Spindle Nose to Table Top:

    29.75"

  • Dimensions:

    84" x 64" x 116" H

  • Weight:

    5,500 LBS

MACHINE EQUIPPED WITH

  • Synchronous 5-axis
  • Tsudakoma TN-131 5-axis Trunnion Table
  • Renishaw Probing included
  • 21 Tool Capacity
  • Extended X-axis Travel: 27.5"
  • Extended Table Length: 33.46"
  • Coolant tank
  • Spindle Chiller
