Doosan 2500LSY 2007

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Max Swing over Bed:

  23.6"

• Max Swing Over Carriage:

  21.6"

• Max Turning Diameter:

  13.0"

• Max Cutting Length:

  29.5"

• X - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Rapid Traverse X-Axis:

  945 IPM

• Rapid Traverse Z-Axis:

  1,181 IPM

• Main Spindle Speed:

  3,500 RPM

• Main Spindle Motor:

  25 HP

• Main Spindle Nose:

  A2-8

• Main Spindle Bar Capacity:

  2.9"

• Main Spindle Bore:

  3.3"

• Sub Spindle Speed:

  6,000 RPM

• Sub Spindle Bar Capacity:

  1.77"

• Sub Spindle Live Tooling Speed:

  5,000 RPM

• Live Tooling Motor:

  7.5 HP

• Turret Capacity:

  8 Positions
