Giddings & Lewis 1600 VTC 2002

machine specifications

• Wire Diameter (inches):

  3333

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Chuck Size (Inches):

  8"

• Max Swing:

  30.3"

• Maximum facing capacity:

  78.74"

• Maximum height from table top to bottom of ram:

  98.43"

• Minimum height under rail from table:

  39.37"

• Table Speeds (Infinitely Variable):

  4 400 RPM

• Ram size:

  9.843"

• Ram Travel:

  68.89"

• Right of center (+ X axis):

  47.63"

• Left of center (-X Axis) :

  47.63"

• Rapid Traverse ( X/Z ):

  787 IPM

• Feedrates per minute infinitely variable,:

  .004 787 IPM (X & Z axis)

• Positioning accuracy A:

  .0006"

• Positioning Repeatability R:

  .0004"

• Reversal B:

  .0002"

• Max Tool Weight:

  22 lbs.

• Max Tool Length:

  15.7"

• Max Tool Diameter:

  2.9"

• Coolant Capacity:

  127 Gallons

• Coolant Pressure:

  45 PSI
