This Machine has been sold and is No longer Available... Find similar machines below

Haas ST-30 2014

MAKE: Haas
YEAR: 2014
TYPE: N/A

MODEL: ST-30
CONTROL: Haas CNC
REF #:

Sell Similar Machine

Get a quote to sell your machine

Buy Similar / Same Machine

View available similar machines

Activate Search Agent

We'll help you find what you need

machine specifications

Chuck Size (Inches):

8"
Max Swing (inches):

17.32"
X - Axis Travel (inches):

15.7" / 400mm
Y - Axis Travel (inches):

15.7" / 400mm
Z - Axis Travel (inches):

14.7" / 375mm
Motor HP:

30
Max RPM:

3400

machine equipped with

Tool Presetter
Chip Conveyor
Programmable Tailstock
Only 800 Hours!

machine description

Pictures are saved on the server: Public - Canon - TollingSpecialists_050216_PZ IMG_4377-4393 SWING DIAMETER S. Over Front Apron: 31.75 " Over Cross Slide: 20.75 " Over Tailstock: 23.0 " CAPACITIES Chuck Size: 10.0 " Max Cutting Diameter (varies with turret) 21.0 " Max Cutting Length (without workholding) 26.0 " Bar Capacity 3.0 " Between Centers 30 " TRAVELS & FEEDRATES X Axis 12.5 " Z Axis 26 " Rapids on X 945 in/min Rapids on Z 945 in/min SPINDLE Max Rating 30 hp Max Speed 3400 rpm Max Torque 300 ft-lb @ 500 rpm Spindle Nose A2-6 Spindle Bore ø 3.50 " TURRET Number of Tools 12 Stations Boring Bar Rear Clearance (from back of turret ) 4.0 " GENERAL Air Required 4 scfm, 100 psi 113 L/min, 6.9 bar Coolant Capacity 55 gal 208 L
