This Machine has been sold and is No longer Available... Find similar machines below

Haas TM1-P 2011

MAKE: Haas
YEAR: 2011
TYPE: N/A

MODEL: TM1-P
CONTROL: Haas
REF #: 620701

Sell Similar Machine

Get a quote to sell your machine

Buy Similar / Same Machine

View available similar machines

Activate Search Agent

We'll help you find what you need

machine specifications

Spindle Taper (CAT/BT):

HSK-463
Spindle Speed:

12,000 RPM
Spindle Motor (HP):

7.5 HP
Chuck Size (Inches):

8"
Tool Changer Type:

60 ATC
Max Swing (inches):

17.32"
X - Axis Travel (inches):

15.7" / 400mm
Y - Axis Travel (inches):

15.7" / 400mm
Z - Axis Travel (inches):

14.7" / 375mm
Options:

Haas Intuitive Programing Solution, 15" Color LCD Monitor, USB Port Interface, Full Sheet Metal Enclosure, 4th Axis Drives and Wiring, Chip Auger, High-Flow Coolant Pump ¾ HP, Programmable Coolant Nozzle, Early Power Failure, Detection Module, Ridge Tapin
Pallet Size (inches):

25"

machine equipped with

Haas Intuitive Programing Solution
15" Color LCD Monitor
USB Port Interface
Full Sheet Metal Enclosure
4th Axis Drives and Wiring
Chip Auger
High-Flow Coolant Pump ¾ HP
Programmable Coolant Nozzle
Early Power Failure
Detection Module
Ridge Tapin

machine description

Travels X Axis: 30 " Travels Y Axis: 12 " Travels Z Axis: 6 " Spindle Nose to Table (~ max): 20 " Spindle Nose to Table (~ min): 4 " Table Length: 47.75 " Table Width: 10.5 " T-Slot Width: 5/8 " T-Slot Center Distance: 4.00 " Number of Std T-Slots: 3 Max Weight on Table (evenly distributed)< 1,000 lb Spindle Max Rating: 7.5 hp Max Speed: 6000 rpm Max Torque: 33 ft-lb @ 1200 rpm Drive System: Direct Speed Belt Drive Taper: BT 40 Bearing Lubrication: Grease packed Cooling: Air Cooled Feed Rates Rapids on X: 400 in/min Feed Rates Rapids on Y: 400 in/min Feed Rates Rapids on Z: 400 in/min Max Cutting: 400 in/min Axis Motors Max Thrust X,Y,Z: 2000 lb Tool Changer: 10 Carousel Machine Dimensions: 96"x72"x103" Machine Weight: 3,850 lbs.
