Hardinge Super Precision CHNC II

machine specifications

• Transport Dimensions:

  91-1/2" x 61-1/2" x 64-1/

• Weight:

  5,000

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Max Swing (inches):

  17.32"

• Turret Capacity:

  8 Positions

• Number of Turrets:

  8

• Spindle Configuration:

  ANSI A2-5"

• Vari-Grip Collet Closer Stroke:

  1/2"

• Hole Through Spindle:

  1-7/8"

• Capacity- With round 16c collets:

  1-5/8"

• Capacity- With step chucks:

  6"

• Capacity- With thru-hole power jaw chuck (chucking capacity):

  5"

• AC Spindle Drive Unit* – Continuous Duty (135% Power Rating):

  7.4 HP

• Max Intermittent Duty (135% Power Rating):

  10 HP

• Max Intermittent Duty (162% Power Rating):

  12 HP

• Max. Threading Diameter:

  8"

• Max. Turning Diameter:

  8"

• Max. Fixture Diameter:

  9"

• Max. Allowable weight on Spindle (including work holding device):

  75 lbs

• Turret - Max X-Axis Travel:

  4 - 1/2"

• Turret - Max Z-Axis Travel:

  12"

• Max distance from Turret Face to Spindle:

  12-1/2"

• Indexing Time-Station 1 to 8 (Station to Station):

  2 seconds

• Min Programmable Resolution and Tool offset capability:

  0.00001

• Compressed Air requirements (min 3/8" ID Air Line):

  70 min. to 90 max psi 5 to 6 cfm

• Recommended Ambient Temperature:

  32 to 104F

• Coolant Sump Capacity:

  30 US gal

• Resonator ( Type ):

  55

• Bar Stock Capacity:

  2.0"

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Pallet Size (inches):

  25"

• Wire Traveling Speed:

  22
