Industrial CNC Craftsmen 510 2016

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Chuck Size (Inches):

  8"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Resonator ( Type ):

  55

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Table Size - L:

  61"

• Table Size - W:

  30"

• X,Y,Z, Traveling Position Accuracy:

  +/-.002

• Frame Structure:

  Steel

• X.Y Structure:

  Anti backlash Rack and Pinion

• Z Structure:

  Orbital Ball Screw

• Max Speed:

  0-900 IPM

• Max Working Speed:

  0-700 IPM

• Spindle Power Motor:

  High Frequency Conversion Water Cooled Motor

• Working Mode:

  24000r/min

• Working Voltage:

  AC220V

• Command:

  MACH controller, G Code

• Interface:

  PC

• XY Working Tolerance:

  < 0.002

• Software:

  Mach3, full function 3d
