Mazak SQT 250MSY 2000

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Chuck Size (Inches):

  8"

• Resonator ( Type ):

  55

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• B – Axis:

  19.7”

• Spindle Motor (HP):

  25 HP

• Spindle Bore:

  2.99”

• Spindle Nose:

  A2-6”

• Spindle Speeds:

  35 - 4000 RPM

• Sub Spindle Body Travel:

  19.7”

• Min. Spindle Indexing (Main Spindle Only):

  .001 Degree

• Distance Between Spindles:

  22.7”

• Max Swing (inches):

  17.32"

• Max. Swing Over Crossslide:

  15.54”

• Max. cutting diameter:

  11.81”

• Turret Type:

  12 TRT

• Boring Bar Type:

  1.25”

• Rotary Tool Speed:

  120-6000 rpm

• Rotary Horse Power:

  5 HP AC

• Rapid Traverse Rates:

  1180 X,Z IPM

• Rapid Traverse Rate:

  708 IPM

• Rapid Traverse C – Axis:

  400 RPM
