Citizen Cincom L-20 VIII 2004

machine specifications

• Max Machining Length:

  8.15"

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  5 HP

• Maximum Machining Diameter:

  .79"

• Main Spindle Indexing:

  Full C-Axis (.001 Deg.)

• Back Spindle Speeds:

  200-8,0000 RPM

• Sub-Spindle Indexing:

  Full C-Axis (.001 Deg.)

• Rotary Tool Speeds:

  200-4,500 RPM

• Back Spindle Max Chucking Diameter:

  .79"

• Turning Tools:

  5 OD Tool Position

• Rotary (Live) Tools:

  7 Live Cross Drilling Mill./Spin.

• Front Endworking Tools:

  3 Front ID Tool Position Block w/ Collet

• Back Endworking Tools:

  3 Backworking ID Tool Block

• Cutting Tool Shank/Sleeve Size:

  1/2" Square Turn / .75" (3) or .63" (4) Bore

• Rapid Traverse (X/Y/Z:

  1257 IPM

• Main Spindle Drive:

  5 HP

• Back Spindle Drive:

  2 HP

• Rotary Tool Drive:

  .4 KW

• Resonator ( Type ):

  55

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Bar Stock Capacity:

  2.0"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Max Swing (inches):

  17.32"

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Chuck Size (Inches):

  8"
