Nakamura-Tome WT-250MMY 2007

machine specifications

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• X-Axis Stroke:

  7.67" (195mm)

• Y-Axis Stroke:

  +/- 1.61"

• Z-Axis Stroke:

  23.6" (600mm)

• B-Axis Stroke:

  24.4" (620mm)

• C-Axis on Main:

  0.001 Deg

• Main Spindle Nose:

  A2-6

• Main Spindle Motor:

  18.5 / 15 kW

• Main Spindle Speed:

  4,500min/-1

• Spindle Bore:

  3.15" (80mm)

• Spindle Bearing Diameter:

  4.33" (110mm)

• Spindle Speed -Driven Tools Stations:

  50-3,600min-1

• Sub Spindle Nose:

  A2-5

• Sub Spindle Bore:

  2.48" (63mm)

• Sub Spindle C-Axis:

  0.001 deg

• Sub Spindle Speed:

  5,000min/-1

• Sub Spindle Motor:

  11/7.5kW

• Sub Spindle Max Bar Capacity:

  2" (51mm)

• Sub Spindle Bearing Diameter:

  3.54" (90mm)

• Sub Spindle Chucking Diameter:

  6.49" (165mm)

• Turning Diameter:

  9.84" (250mm)

• Turning Length:

  21.85" (555mm)

• Shank Diameter:

  0.98" (25mm)

• Drill Shank Diameter:

  1.26" (32mm)

• Number of Turrets:

  2

• Number of Driven Tool Positions:

  2x 12 Pos

• Max Bar Capacity:

  2.55" (65mm)
