DMG DMF 260 Y1100 2014

machine specifications

• Table Size - L:

  61"

• Table Size - W:

  30"

• Max Load on Table:

  8818 lbs

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• B - Axis Travel:

  +/- 100 DEGREES

• Integrated NC Table Dimension:

  41.3"

• Table Load on Integrated NC Table:

  2645 LBS

• Spindle Nose:

  A2-8

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  59/42 HP AC

• Rapid Travese Rates:

  708 IPM B / 1574 IPM X,Y,Z

• Cutting Federate:

  1574 IPM

• Tool Changer Type:

  60 ATC

• Max Tool Length:

  15.7"

• Max Tool Dia.:

  4.5" / 6.3"

• Max Tool Weight:

  22 lbs.
