Mazak Integrex j-200 2013

machine specifications

• Maximum Swing :

  20.87"

• Max Turning Diameter:

  19.69"

• Maximum Cutting Length:

  19.69"

• X Axis Travel:

  17.72 (X1, X2, X3)

• Y Axis Travel:

  7.87 (Y1, Y2, Y3)

• Z Axis Travel:

  21.65 (Z1, Z2, Z3)

• Main Spindle Chuck:

  10"

• Main Spindle Bar Capacity:

  2.5"

• Main Spindle Speed:

  4,200 rpm

• Main Spindle Chuck Type:

  Hydraulic

• Main Spindle Bore Diameter:

  3"

• Main Spindle Horsepower:

  (CONT. /30 MINS) 15

• ATC Magazine Capacity:

  36

• Weight:

  13,530 LBS

• B Axis Rotary Tool Spindle Speed:

  12000 rpm

• B-Axis Rotary Tool Spindle Horsepower:

  10 hp

• Milling Spindle Synchronous Tapping:

  Yes

• Tool Eye Automatic Front Spindle:

  yes

• Coolant Thru Milling Head:

  yes
