Okuma Multus U4000-2SW x 1500 2022

Front Access ATC for Easy Operation (Capto C6), Schunk THW3-315 Quick Jaw Change Chuck on Left and Right, Thread Phase Matching,

Make
Okuma
Control
Okuma OSP-300

model
Multus U4000-2SW x 1500
Reference
#3655567

year
2022

type
5 Axis Machining Center

Get quote make offer contact us Sell Your Okuma

machine specification

LEFT SPINDLE
3000 RPM

RIGHT SPINDLE
3800 RPM

RIGHT SPINDLE
SR-1670 Hyd. Cylinder & Drawtube

H1 SPINDLE (MILLING)
30 HP 89lbs-ft

TORQUE
12000 RPM - Low Profile

UPPER TURRET
80 Position (Capto C6)

LOWER TURRET
12 Position (Static Tooling)

MAX TURNING DIA.
12.59"

MAX WORK LENGTH
78.7"

X AXIS TRAVEL
27.36"

Y AXIS TRAVEL
11.81" (5.91"/-5.91")

Z AXIS TRAVEL
82.6"

C AXIS
360,000 Degrees

B AXIS
-30 Degrees/ +210 Degrees

machine equipped with

FRONT ACCESS ATC FOR EASY OPERATION (CAPTO C6)
COLLISSION AVOIDANCE SYSTEM (CAS)
MULTI-TAB TRANSFORMER (100KVA)
BB SPINDLE (A2--11) W/F2511 CYL + DRAWTUBE ON MAIN
NC B-AXIS W/CONTOURING (ALLOWS FOR CONTINOUS 5-AXIS MOVES)
80 POSITION CAPTO C6 ATC UPGRADE W/ BAR FEED COVER
LATHE TOOL INDEX FUNCTION - MULTI EDGE (12 POSITION)
NEGATIVE TOOL RADIUS COMPENSATION
AUTO GAUGING RENISHAW RMP600 RMI-Q CAPTO C6
Y-AXIS GAUGING W/SLOPE GAUGING
TOUCHSETTER AUTO FOR 2 SADDLE
RIGHT DISCHARGE DRUM FILTER CHIP CONVEYOR (HIGH DISCHARGE)
HYDRAULIC OIL TEMPERATURE REGULATOR
TYPE B NIAGARA SHOWER COOLANT
STEP STOOL GRATE IN CONVEYOR FOR OPERATOR
8 SETS OF SPARE M-CODES
MACHINE ADVANCED ONE TOUCH IGF CONVERSATIONAL PROGRAMMING
STEADY REST ENABLE/DISABLE SWITCH
VARIABLE SPINDLE SPEED THREADING ON LEFT/MAIN
THREAD PHASE MATCHING
FEED HOLD DURING THREADING
INVERSE TIME FEED FUNCTION
SCHUNK THW3-315 QUICK JAW CHANGE CHUCK ON LEFT AND RIGHT
LNS STEADY REST/FOLLOW REST PACKAGE
ROYAL PRODUCTS ROYAL MIST COLLECTOR PACKAGE FX-1200
MP SYSTEMS HIGH PRESSURE COOLANT PUMP (1000PSI ON UPPER AND LOWER) & 50-GAL RESERVOIR
PC ADVANCED ONE TOUCH IGF CONVERSATIONAL PROGRAMMING

machine description

Used Okuma Multus U4000-2SW x 1500. This pre-owned 5 Axis Machining Center is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Okuma 5 Axis Machining Center we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
