Walter HP-600 2004

machine specifications

• Longitudinal traverse (x-axis): :

  480 mm / 18.90"

• Vertical traverse (y-axis)::

  320 mm / 12.6"

• Cross traverse (z-axis): :

  700 mm / 27.56"

• Rotary table swiveling range (c-axis)::

  +/- 200 deg

• Work head spindle: :

  ISO 50

• Max. diameter of workpiece: :

  320 mm / 12.6"

• Max. length of workpiece for peripheral grinding::

  370 mm / 14.57"

• Max. length of workpiece for face grinding: :

  320 mm / 12.6"

• Precicion in linear resolution::

  0.0001mm / 0.000004"

• Max. diameter wheel: :

  200 mm / 7.87

• Peak performance grinding spindle::

  30 KW / 40 HP

• Grinding spindle speed::

  0 to 10,000 RPM

• Power requirement::

  35KVA, 460 v, 60hz
