Haas ST-10 2022

machine specification

• CAPACITY
• 12" x 16"

• CHUCK SIZE
• 6.5"

• PART SWING MAX
• 16.5"

• MAX CUTTING DIAMETER
• 12.00" with bot turret

• MAX CUTTING LENGTH
• 16.0"

• BAR CAPACITY
• 1.75"

• SPINDLE NOSE
• A2-5

• MAX RATING
• 15.0 hp

• MAX SPEED
• 6000 rpm

• MAX TORQUE
• 75.0 ft-lbf @ 1300 rpm

• SPINDLE BORE
• 2.31"

• NUMBER OF TOOLS
• 12-Station BOT

machine equipped with

• TAILSTOCK W/ HYDRAULIC QUILL (4" STROKE/MT3 TAPER)
• AUTOMATIC TOOL PRESETTER
• HAAS SPINDLE LINER KIT
• EZ-PULLER BAR PULLER
• (2) S-SCLCR103 BORING BAR
• RF123G079-12B GROOVER
• HAAS AUTOGRIP SYSTEM
• 1/2"- 1.375"- 5/8" - `.5"- .375"- 1.25"- 1.625" - .75" (5) 1" DIAMETER HAAS BORING BAR TOOL HOLDERS
• (1) 1.25" DIAMETER HAAS BORING BAR TOOL HOLDER
• (4) TECHNICS C1"X ER20M-140
• (35) ER-COLLETS (VARIOUS SIZES)
• MIST COLLECTOR
• 671 HOURS

machine description

Used Haas ST-10. This pre-owned CNC Lathe is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Haas CNC Lathe we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
