Clausing 3000MT 2012

machine specifications

• Resonator ( Type ):

  55

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Pallet Size (inches):

  25"

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Table Size - L:

  61"

• Chuck Size (Inches):

  8"

• Bar Stock Capacity:

  2.0"

• Swing over Bed:

  18.1"

• Max Swing (inches):

  17.32"

• Swing over cross slide:

  10.6"

• Swing in Gap:

  28.7"

• Gap Width in Front of Faceplate:

  8.5"

• Spindle Center High From Floor:

  45"

• Width of Cross Slide:

  8"

• Type of Cross Slide Ways:

  Dovetail

• Bed Width:

  15.7"

• Type of Bed Ways:

  V and Flat Ways

• Coolant Tank Capacity:

  25 Gallons

• Spindle Nose:

  D1-8

• Spindle front Bearing I.D.:

  5.25"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Bore:

  3.07"

• Spindle Speed - Low Range:

  1 - 247 RPM

• Spindle Speed - Medium Range:

  1 - 740 RPM

• Spindle Speed - High Range:

  1 - 2200 RPM

• Spindle Drive:

  Variable AC

• Spindle Motor (Cont./30 min):

  10/15 HP

• Min. Spindle Speed for Full Power:

  71 RPM

• Power Consumption:

  26 KVA

• Cross Slide Travel (X Axis):

  11.7"

• X Axis Rapid Traverse:

  315"/min

• X Axis and Z Axis Feed Rate:

  .0012" - 236"/rev.

• X Axis Thrust (continuous):

  1,464 lbs.

• X Axis Ballscrew:

  25 x 4 mm

• Saddle Travel (Z Axis):

  55.0"

• Z-Axis Rapid Traverse:

  394"/min

• Z Axis Thrust (continuous):

  2,196 lbs

• X Axis Ballscrew:

  40 x 8 mm

• Positioning Accuracy:

  ± 0.0002"

• Repeatability:

  ± 0.0001"

• Tailstock Taper:

  6MT

• Tailstock Quill Diameter:

  3.74"

• Spindle Speed:

  12,000 RPM
