Daewoo Puma 230C 2000

machine specification

• MAX TURNING DIAMETER
• 21.7"

• MAX TURNING LENGTH
• 41.1"

• MAX BAR CAPACITY
• 3.0"

• SWING OVER BED
• 20.1

• X-AXIS TRAVEL
• 14.3"

• Z-AXIS TRAVEL
• 43.5"

• RAPID TRAVERSE (X)
• 787 IPM

• RAPID TRAVERSE (Z)
• 1000 IPM

• SPINDLE NOSE
• A2-8

• SPINDLE BORE
• 3.54"

• SPINDLE MOTOR
• 50 HP

• TURRET INDEX TIME
• 0.1 Second

• TAILSTOCK TAPER
• MT-4

• TAILSTOCK QUILL DIAMETER
• 2.95"

• TAILSTOCK QUILL TRAVEL
• 4.7"

• POWER
• 220v / 3-Phase

machine equipped with

• 10" HYDRAULIC CHUCK
• COOLANT SYSTEM
• TOOL PRESETTER
• TAILSTOCK
• MANUALS

machine description

This used Daewoo CNC Lathe features a spindle speed of 3500 RPM, a max turning diameter of 13.78", a Fanuc Series 21-T control, and a 20.2" swing over bed. This lathe comes equipped with 10" hydraulic chuck, a coolant system, a tool presetter, a tailstock and a full set of manuals. This CNC Lathe was new in 2000. For more information call us at 312.226.4150.
