Dainichi H-NC 160x400 2008

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• X - Axis Travel (inches):

  15.7" / 400mm

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Y - Axis Travel (inches):

  15.7" / 400mm

• Resonator ( Type ):

  55

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Max Swing (inches):

  17.32"

• Swing over cross slide:

  50 "

• Maximum Machining Diameter:

  50 "

• Dist. Between Centers (inches):

  157.5"

• Spindle Speed:

  12,000 RPM

• Spindle Bore:

  4.09 "

• Spindle Motor (HP):

  74 HP

• Turret Capacity:

  8 Positions

• Quill Diameter:

  12 "

• Chuck Size (Inches):

  8"

• Hole Thru:

  4"
