DMG Mori NLX 2500SY/700 2017

machine specifications

• Spindle Motor (HP):

  25/22 HP

• Spindle Taper (CAT/BT):

  HSK-463

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Dist. Between Centers (inches):

  28.7"

• Vertical Travel of Ram:

  4444

• Spindle Bore / Bar Capacity / Nose:

  3.58"/3.1"/A2-8

• Sub Spindle Speeds Minimum - Maximum:

  60 - 6,000 RPM

• Maximum Turning Length:

  27.75"

• Maximum Turning Diameter:

  14.01"

• Motor:

  30 min./cont: 15/10 HP

• Number of Positions:

  12 Stations

• Rotary Tool Speed:

  6,000 RPM

• Rotary Tool Motor (30 min. / continuous):

  15/10hp

• Rapid Traverse (X & Z ):

  1,181 IPM

• Feed Rate (X & Z ):

  0.04-787 IPM
