Gildemeister GM67CNC 2000

machine specifications

• Radial stroke X:

  4.33"

• Longitudinal stroke Z:

  22.24"

• Rapid Traverse X:

  15m/min

• Rapid Traverse Z:

  20m/min

• Turret mounted on compound slide - Number of tool stations:

  12

• Shank diameter according to DIN 69880:

  1.18"

• Tool holder mounted on front slide - Number of tool stations:

  2

• Drive capacity 4 KW by power rate:

  5000 rpm

• Max Speed:

  6000 rpm

• Max driven tools:

  12

• Drive for rotating tools, turret:

  2

• Drive for revolver position:

  2

• Bar holder for bar with length:

  157.48"

• Min Diameter:

  .98"

• Max Diameter:

  2.75" (excl. hexagonal bars)
