Haas SL-40 2000

machine specifications

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Y - Axis Travel (inches):

  15.7" / 400mm

• Spindle Taper (CAT/BT):

  HSK-463

• Max Swing (inches):

  17.32"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• X - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  40 HP

• Chuck Size (Inches):

  8"

• Bar Stock Capacity:

  2.0"

• Dist. Between Centers (inches):

  51"

• Over Front Apron:

  40"

• Over Cross Slide:

  25"

• Maximum Cutting Diameter:

  25.5"

• Maximum Cutting Length:

  44"

• Maximum Cutting Length W/Standard Workholding:

  42.5"

• Torque:

  1,400 Ft-Lb @ 150 Rpm

• Spindle Nose:

  Spindle Nose: A2-8

• Spindle Bore:

  4.62"

• Draw Tube Bore:

  4.06"

• Axis Motor Max Thrust:

  3,400 Lbs

• Rapids:

  710 Ipm

• Number of Tools:

  10

• OD vs ID Tools:

  Any Combination

• Tool Hole In Turret:

  2"

• Tool Size (OD turning):

  1"

• Tool Holder Bores:

  .750", 1", 1.25", 1.50"

• Boring Bar Rear Clearance (From Turret Face):

  4.25"

• Index Time (one tool):

  1 Second

• Coolant:

  77 Gallons

• Air Requirement:

  3 Scfm @ 100 Psi

• Electrics:

  230 Volts, 3 Ph, 60 Cyc
