Haas TL-2 2016

machine specifications

• Wire Diameter (inches):

  3333

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Over Front Apron:

  20.0 in

• Over Cross Slide:

  11.0 in

• Chuck Size (Inches):

  8"

• Max Cutting Diameter (varies with turret):

  16.0 in

• Max Cutting Length (without workholding):

  48 in

• Between Centers:

  48 in

• Rapids on X:

  450 ipm

• Rapids on Z:

  450 ipm

• Max Thrust X:

  3894 lbf

• Max Thrust Z:

  1947 lbf

• Spindle Nose:

  A2-5

• Drive System Direct Speed:

  Belt Drive

• Max Rating:

  10.0 hp

• Max Speed:

  1800 rpm

• Max Torque:

  108 ft-lbf @ 355 rpm

• Spindle Bore ø:

  2.30 in

• Inline Air Hose:

  3/8 in

• Coupler (Air):

  3/8 in

• Air Pressure Min:

  80 psi

• Spindle Speed:

  1800 rpm

• Drive System Direct Speed:

  Belt Drive

• spindle power:

  10.0 hp

• Input AC Voltage (1 Phase):

  220 VAC

• Full Load Amps (1 Phase):

  40 A

• Input AC Voltage (3 Phase) - Low:

  220 VAC

• Full Load Amps (3 Phase) - Low:

  25 A

• Input AC Voltage (3 Phase) - High:

  440 VAC

• Full Load Amps (3 Phase) - High:

  13 A

• Read more
