Mazak Integrex 100-2SY 2004

machine specifications

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• Chuck Size (Inches):

  8"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Max Swing (inches):

  17.32"

• Max Swing Over Carriage:

  11.42"

• Maximum Cutting Diameter:

  18.5"

• Maximum Cutting Length:

  29.72"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Travel B Axis:

  225 Deg/.001 Deg

• Spindle Nose:

  A2-5

• Spindle Bore:

  2.4"

• Bar Stock Capacity:

  2.0"

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  10 HP

• Main & Subspindle Indexing:

  .001 Degree

• Rotary Tool Motor:

  7.5 HP

• Rotary Tool Speed:

  10,000 RPM

• Tool Changer Type:

  60 ATC

• Rapid Traverse Rate X:

  1181 IPM

• Rapid Traverse Rate Y:

  1024 IPM

• Rapid Traverse Rate Z:

  1299 Ipm

• Read more
