Mazak Integrex 200 IVST 2007

machine specifications

• X - Axis Travel (inches):

  15.7" / 400mm

• X – Axis Travel Upper / Lower:

  22.8"/5.91"

• Z – Axis Travel Upper / Lower:

  60.82"/58.66"

• B – Axis Travel:

  225 Degrees

• B – Axis Clamping:

  5 Degrees

• W – Axis Travel Sub Spindle:

  62.3"

• C – Axis Main Spindle Min Indexing:

  .001 Degree

• Spindle Speed:

  12,000 RPM

• Spindle Bore:

  2.99"

• Spindle Taper (CAT/BT):

  HSK-463

• Sub Spindle Speed:

  5,000 RPM

• Max Swing (inches):

  17.32"

• Maximum Swing Over Lower Turret:

  16.5"

• Maximum Machining Upper/Lower Turret:

  26" / 10.6"

• Maximum Cutting Length Between Spindles:

  61"

• Lower Turret Positions:

  9 Tool Drum

• Lower Turret Milling Spindle Speeds:

  6,000 RPM

• Tool Changer Type:

  60 ATC

• Bar Stock Capacity:

  2.0"

• Rapid Traverse Rates X, Z, Y, W:

  555, 555 RPM – 1496, 1496, 1023, 1181 IPM

• Resonator ( Type ):

  55

• Z - Axis Travel (inches):

  14.7" / 375mm

• Chuck Size (Inches):

  8"

• Y - Axis Travel (inches):

  15.7" / 400mm

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Pallet Size (inches):

  25"

• Wire Traveling Speed:

  22
