Mighty Viper VT-33BL 2007

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Y - Axis Travel (inches):

  15.7" / 400mm

• Pallet Size (inches):

  25"

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• X-Axis Rapid:

  787 IPM

• Z-Axis Rapid:

  944 IPM

• Max Swing (inches):

  17.32"

• Swing over cross slide:

  18.9"

• Max Turning Diameter:

  22"

• Max Turning Length:

  41.3"

• Spindle Motor (HP):

  50 HP

• X & Z Axis Servo Motors:

  5.4 HP

• Thru Spindle Hole Diameter:

  5.15"

• Spindle Speed:

  12,000 RPM

• Spindle Size:

  A2-11

• Bar Stock Capacity:

  2.0"

• Turret Capacity:

  8 Positions

• Turret Index Time:

  0.9 Second

• Shank Height Square Tool:

  1.0"

• Shank diameter for boring bar:

  1.6"

• Turret Type:

  Static Block Tool Turret

• Tailstock Travel:

  35.4"

• Tailstock Spindle Diameter:

  4.3"

• Tailstock Spindle Travel:

  3.9"

• Taper Hole of Tailstock Spindle:

  MT-5

• Tailstock Type:

  Hydraulic
