Mori Seiki ZT1500YB 2005

machine specifications

• Spindle Motor (HP):

  30 HP

• Max Swing (inches):

  9.8"

• X - Axis Travel (inches):

  5.51"

• Y - Axis Travel (inches):

  1.97"

• Z - Axis Travel (inches):

  27.56" / 27.17"

• Bar Stock Capacity:

  2"

• Spindle Speed:

  5,000 RPM

• Distance between Spindle Noses:

  39.37"

• Max Turning Diameter:

  7.48"

• Max Length:

  9.25"

• Main Spindle Bore:

  24"

• Spindle Nose:

  A2-5, 2.87

• Sub Spindle Bore:

  3.2"

• Sub Spindle Bar Cap:

  2.5"

• Sub Spindle Nose:

  A2-5

• Rotary Tool Speed (Turret One/Two):

  6,000 RPM

• Rotary Tool Motor (5 min.):

  7.5 HP

• Rotary Tool Motor (15 min.):

  5 HP

• Rotary Tool Motor (Cont.):

  3 HP

• Number Of Positions (Turret One/Two):

  12 Tools

• B-Axis Travel (Sub-Spindle):

  30.51"

• C-Indexing:

  360,000°

• Rapid Traverse (X / Z / Y):

  708 / 944 / 236 IPM

• Sub Spindle Rapid Traverse / C-Axis:

  944 / 410 IPM
