Okuma Multus B400W 2000 2011

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Chuck Size (Inches):

  8"

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• W-Axis Travel:

  80.71"

• Spindle Speed:

  12,000 RPM

• Max. Turning Diameter:

  27.95"

• Dist. Between Centers (inches):

  78.74”

• Max Swing (inches):

  17.32"

• Main Spndle Nose:

  A2-11

• Main Spindle Speed:

  2,800 RPM

• Opposed Spindle Nose:

  A2-11

• Opposed Spindle Speed:

  2,800 RPM

• C-Axis Increment:

  .001º

• B-Axis Index Angle:

  -30º to 195º

• B-Axis Index Increment Angle:

  .001º

• Turret Type:

  H1

• Rotary Tool Speed:

  6,000 RPM

• ATC Magazine:

  80 Capto C6

• Cut time hours:

  1,541

• Main Spindle Drive Motor:

  30/20 HP

• Tool Changer Type:

  60 ATC
