Peddinghaus MDL 1000B Ocean Avenger Drill Line 2011

machine specifications

• Motor:

  20 HP

• Max Thickness:

  6"

• Air Pressure:

  90 PSI

• Hydraulic Pressure:

  1750 PSI

• Spindle Travel:

  13"

• Spindle Speed:

  200-850 RPM

• Drill Diameter:

  5/16" to 1-9/16"

• Capacity:

  39"

• max machining height/width:

  39.38"

• Maximum length piece part:

  Based on Table Length 60ft Max

• Max X axis travel speed:

  120 ft/min

• Max Y axis travel speed :

  120 ft/min

• air consumptions :

  20 cu. ft/min

• web probe stroke :

  10"

• available clamping force :

  2945-6872 lbs

• Power per spindle:

  13.5 hp

• Drill Spindle rapid advance speed:

  192 ipm

• variable feed :

  2 -10 ipm
