Fanuc Robodrill T21-iDL 2003

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Chuck Size (Inches):

  8"

• Throat Depth:

  9.45"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Resonator ( Type ):

  55

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Motor (HP):

  7.5 HP

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Nose to Table Top:

  5.9" - 18.9"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Table Load Capacity:

  550 lbs.

• Tool Changer Type:

  60 ATC

• Max Tool Diameter:

  3.15"

• Max Tool Length:

  7.87"

• Max Tool Weight:

  6.6 lbs.

• Rapid Traverse Rates:

  2000 IPM
