Okuma Multus B300II-W 2014

machine specifications

• Pallet Size (inches):

  25"

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Maximum Turning Diameter:

  24.80”

• Distance Between Spindles:

  35.43”

• Spindle Nose:

  A2-8 - Main, A2-6 - Sub-Spindle

• Spindle Speeds:

  Main Spindle 38 - 3,800 Rpms

• Spindle Speeds:

  Sub-Spindle 50 - 6,000 Rpms

• Bar Capacity Main Spindle:

  2.75”

• Bar Capacity Sub-Spindle:

  2.00”

• Horsepower Both Spindles:

  20 Hp, Intregral

• Tool Changer Capacity:

  Atc 40 Tools, Capto C6 Tools

• Rapid Traverse Rates:

  1,575 / 1,023 / 787 Ipm; X & Z / Y / W

• X-Axis Travel:

  22.83 (+22.04 ~ -.79 In)

• Y-Axis Travel:

  6.30 Inches (+3.15” / -3.15”)

• Z-Axis Travel:

  36.81”

• W-Axis Travel:

  Right Spindle 39.37”

• C-Axis Travel:

  Main & Sub 360 Degrees, With Disk Brake

• B-Axis Travel:

  .001 Degree Positioning

• H1 Spindle Taper:

  Capto C6

• H1 Spindle Range:

  50 – 10,000 Rpms

• H1 Spindle Motor:

  15/10 Hp (5 Minute Continuous)

• Maximum Tool Length:

  11.81”

• Maximum M Tool Diameter:

  3.54”/5.12” If No Adjacent Tool

• Maximum Tool Weight:

  17.6 Lbs.
