Bystronic BySmart Fiber 4020 2021

machine specifications

• Working Area:

  13.1' x 6.6'

• Laser Source Power:

  10 kW

• Wavelength:

  1060-1080 nm

• Automation:

• Model:

  ByTrans 4020 Extended

• Age:

  2021

• Function:

  Automatic Sheet loading/unloading

• Processing Capacity:

• Mild Steel:

  1" (25 mm)

• Stainless Steel:

  1.5" (40 mm)

• Aluminum:

  1.25" (30 mm)

• Brass:

  0.63" (16 mm)

• Cooper:

  0.5" (12 mm)

• Sheet Capacity:

  157" x 79" (4000 x 2000 mm)

• Max Sheet Weight:

  3300 lbs (1500 kg)

• Max Load Height (ByTrans):

  Approximately 10-12" stack

• Maximum Positioning Speed:

  Up to 5,500 IPM

• Table Change Time:

  Approx. 27 Seconds

• Z Axis Travel:

  3.9"

• Motion System:

• Simultaneous Positioning Speed:

  Up to 554 in/min (140 m/min)

• Axis Acceleration:

  Up to 1.5 G

• Positioning Accuracy:

  ±0.004" (±0.1 mm)

• Repeatability:

  ±0.0016" (±0.04 mm)

• Resonator:

• Source Type:

  Fiber Laser

• Power:

  10000 Watts

• Efficiency:

  ~40–50% wall-plug efficiency

• Cooling:

  Integrated chiller

• ByTrans Extended 4020:

• Features Include:

• Automatic raw material loading:

• Automatic skeleton/unload handling:

• Shuttle table system:

• Material tower integration capability:

• Lights-out production capability:

• Reduced operator handling:
