Amada HFA-400W

machine specifications

• Cutting Capacity - Round (Diameter):

  1.18" - 16.54"

• Cutting Capacity - Rectangle (W X H):

  16" x 16"

• Work Load Capacity:

  5,511 lbs

• Blade Size:

  15ft x 0.050" x 1-1/2"

• Blade Speed:

  56-295ft/min Stepless

• Type:

  Main and rear vise

• Saw Blade:

  7.5 hp/ 5.5 kW

• Cutting Fluid Pump Motor:

  1/4 hp / 0.18 kW

• Power Supply Voltage:

  AC220V±10%, 3 PH, 60 Hz or AC440V±10%, 3 PH, 60 Hz

• Power Requirement:

  11 kVA

• Cutting Fluid Tank Capacity:

  31.7Gal/ 120 liters

• Pump Type:

  Centrifugal Electric Pump

• Hydrauic Tank Capacity:

  10.6 gal/ 40 liters

• Hydraulic Pump:

  Variable-Discharge Vane Pump

• Hydraulic Pressure:

  498 psi 3.5 MPa (35 kgf/cm2)

• Stroke:

  19.6"

• Length:

  0.39-999.999"

• Machine Dimensions:

  Head-Up Position 89.5" x 106.2" x 95.5"

• Table Height:

  31.5"

• Machine Weight:

  4,850 lbs
