Doosan DBC-130II 2013

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• Resonator ( Type ):

  55

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Throat Depth:

  9.45"

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Table Size - W:

  30"

• Table Size - L:

  61"

• Table Capacity:

  33,000 LBS

• Distance from Table Center to Spindle Nose:

  27.5" - 90.5"

• Distance from Table Top to Spindle Center:

  0-78.7"

• Spindle Diameter:

  5.13"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Spindle Torque:

  2,475.2ft/lbs

• Spindle Motor (HP):

  40 HP

• Table Indexing:

  .001 N/C Rotary Table

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• W Axis Travel (Inches):

  27.5"

• Tool Changer Type:

  60 ATC

• Max. Tool Length:

  23.6"

• Max. Tool Diameter:

  9.8"

• Max. tool weight:

  55 LBS
