Mazak FH 6000 2000

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Resonator ( Type ):

  55

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Pallet Size (inches):

  25"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Pallet Index:

  .001 positioning

• Distance of Spindle Center to Top of Pallet:

  3.9" - 35.4"

• Maximum Table Load:

  2,200 lbs.

• Max Workpiece Height:

  40"

• Max Workpiece Diameter:

  36"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Motor (HP):

  40/30 HP

• Spindle Speed:

  12,000 RPM

• Spindle Speed Increment:

  1 RPM

• Tool Changer Type:

  60 ATC

• Obtains Full HP:

  480 RPM

• Constant Torque Range:

  35 – 480 RPM

• Number Of Ranges:

  1
