Bystronic PR 320X4100 2007

machine specifications

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Stroke (SPM):

  10.43"

• Table Size - L:

  61"

• Working Length:

  161.4”

• Max Press Force:

  320 Metric tons

• Rapid Approach:

  7.48 IPS

• Bending Cycle:

  .39 IPS

• Rapid Return:

  5.90 IPS

• Weight:

  48,501 Lbs

• Main Motor Power:

  36 KW

• Total Connected Load:

  37 KW

• Operating Volts:

  480V , 3ph, 60hz

• Nominal Fuse:

  80 amps
