Amada Ensis 3015 AJ + ASF-EU 2016

machine specifications

• Turret Capacity:

  8 Positions

• Chuck Size (Inches):

  8"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Resonator ( Type ):

  55

• Sheet Size - L:

  120"

• Sheet Size - W:

  60"

• Travel Method:

  Stationary table, X, Y, cutting head Z

• Control Method:

  X, Y, and Z (simultaneous 3-axis control)

• Drive Motors:

  FANUC AC servo motors

• Max. Axis Positioning Speed (X, Y):

  4,724"/min. per axis (6,693"/min. 45° vector)

• Max. Z-Axis Speed:

  4,724"/min.

• Repeatability:

  ±0.0002"

• Max. Material Weight:

  2,000 lbs.

• Data Storage:

  Compact flash drive
