Amada Gemini FO 3015 NT 2006

machine specifications

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Travel Method:

  Stationary table, X, Y and Z-axis for cutting

• Drive Motors:

  Fanuc AC servo motors

• Max Sheet Size:

  61" (Y) x 122.8" (X)

• Max Axis Travel:

  61" (Y) x 122.8" (X) x 7.87" (Z) *

• Max Axis Positioning Speed:

  3,150 inches per minute (80m/min)

• Per axis:

  4,554 inches per minute 45o vector.

• Max Speed Z-Axis:

  2,362 inches per minute

• Positioning Accuracy:

  0.0004" / 20"

• Maximum Material Weight:

  1,875 lbs

• Assist Gas:

  4 ports with NC pressure Control

• Electrical Requirement:

  208V, 3 Phase, 60Hz, 10KVA

• Display:

  LCD Color Graphics Display

• LCD Color Graphics Display:

  0.0001" (X, Y, Z)

• Minimum Travel Unit:

  0.0001" (X, Y, Z)

• Sheet Width:

  61"

• Sheet Length:

  122.8"

• Wattage:

  4000 Watts

• IPM:

  3149

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Bar Stock Capacity:

  2.0"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Pallet Size (inches):

  25"

• Max Swing (inches):

  17.32"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Chuck Size (Inches):

  8"
