Cincinnati CL-940A 2014

machine specifications

• Chuck Size (Inches):

  8"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Cutting Capacities - Nitrogen:

  20 Ga. To 1/4"

• Cutting Capacities - Oxygen:

  10 Ga. To 1/2"

• Positioning speed:

  12,000 Ipm

• Rapid Traverse X & Y Axis:

  8,500 Ipm

• Rapid Traverse X & Y Axis:

  Simultaneous 12,020 Ipm

• Rapid Traverse Z Axis:

  1,700 Ipm

• Normal Jog (X And Y Axis):

  300 Ipm

• Rapid Traverse Jog (X And Y Axis):

  1200 Ipm

• Rapid Traverse Jog (Z Axis):

  1700 Ipm

• Accelerations X And Y Axis:

  1.65 G

• Accelerations Z-Axis:

  2.00 G

• Absolute Positioning X & Y Axis:

  +/- 0.001"

• Repeatability X & Y Axis:

  .001"

• Lens Focal Length:

  7.5"

• Assist Gas Pressure Adjustment:

  5 - 400 PSI

• Microprocessor:

  Multi-Processor

• Operating System:

  Windows Embedded Standard (Wes)

• Nozzle Cooling Purge:

  Compressed Air Filter/Dryer

• Compressed air supply:

  480 Scfm @ 80 To 140 Psig

• Type:

  Solid State Ytterbium Fiber

• Power Output:

  4000 Watt CW 2%

• Modes Of Operation:

  Continuous Wave, Quasi-Continuous Wave

• Pulse Frequency:

  8 - 5000 Hz

• Range:

  10 - 105%

• Beam Quality:

  50 Micron Feeding Fiber

• Polarization:

  Random

• Voltage:

  460v ~ 3 Phase
