Mazak Optiplex 3015 2012

machine specifications

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Machine Structure:

  Flying Optics

• Laser Type:

  CO2 Gas

• Maximum Workpiece Dimensions:

  60.039 in X 120.078 in

• Maximum Workpiece Weight:

  2,050 lbs.

• Work Table Height:

  35.4"

• Axial Feed Acceleration X, Y, Z:

  1.2 g

• Motion Drive System Design X, Y Axis:

  Rack and Pinion Drive, Z-Axis Ball Screw Drive

• Rapid Travel Rate X, Y Axis::

  4,724 IPM

• Rapid Travel Rate Z Axis:

  2,362 IPM

• Positioning Accuracy X, Y Axis:

  0.002 in/19.68 in

• Positioning Accuracy Z Axis:

  0.0004 in/3.94 in

• Repeatable Accuracy X,Y,Z Axis:

  0.0012 "

• Total Electrical Requirement:

  76.0 kva
