Mazak Optiplex 3015 Fiber II 2015

machine specifications

• Turret Capacity:

  8 Positions

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• Table Size - W:

  30"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Chuck Size (Inches):

  8"

• V-Axis Travel:

  5555

• Power Output:

  4,000 Watts

• Resonator:

  IPG Fiber Laser Source

• Machine Structure:

  Flying Optics

• Rapid Travel Speed (X,Y):

  4,724 ipm

• Positioning Accuracy X, Y Axis:

  0.0002"/19.69"

• Positional accuracy Z:

  0.0004"/3.94"

• Total Electrical Requirement:

  71 kVA

• Installation Dims W x D:

  394" x 240"

• CPU:

  64 bit

• Display screen:

  19" SXGA Color TFT

• Memory Capacity:

  16 GB (program memory capacity: 1 GB)

• Position detection system:

  Encoder

• Minimum Command Unit:

  0.0001"

• Number of Control Axis:

  3

• Z-axis:

  Ball Screw Drive

• Motion Drive System Design X, Y Axis:

  Rack and Pinion Drive

• Max Workpiece Weight:

  2,050 lbs

• X-Axis Travel:

  14.3"

• Y-Axis Travel:

  27.6"

• Z-Axis Travel:

  43.5"

• Work Table Height:

  35.43"

• Max Thickness Mild Steel:

  1.0”

• Max Thickness Stainless Steel:

  0.75”

• Max Thickness Aluminum:

  0.63”

• Program input system:

  EIA/ISO

• Repeatable Accuracy X, Y axis:

  0.0012"
