Mazak Optiplex 4020 2016

machine specifications

• Pallet Size (inches):

  25"

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Chuck Size (Inches):

  8"

• Laser Output:

  4.0kW

• Laser Type:

  CO2

• Machine Structure:

  Flying Optics

• X-Axis Travel:

  14.3"

• Y-Axis Travel:

  27.6"

• Z-Axis Travel:

  43.5"

• Work Table Height:

  35.4”

• Max Thickness Mild Steel:

  1.000”

• Max Thickness Aluminium:

  0.375”

• Max Thickness Stainless Steel:

  0.500”

• Motion Drive System X, Y axis:

  Rack & Pinion

• Motion Drive System Z axis:

  Ball Screw

• Number of Control Axis:

  3

• Rapid travel speed (X, Y):

  4,724 ipm

• Positioning Accuracy X, Y Axis:

  0.002 in/19.68”

• Positioning Accuracy Z Axis:

  0.0004 in/3.94”

• Repeatable Accuracy:

  0.0012” (X,Y Axis)

• Machine Footprint (W x D):

  560” x 278”

• Total Electrical Requirement:

  80 kVA

• Control:

  Meldas 500 Series

• CPU:

  64 bit

• Display screen:

  15” Color LCD (TFT)

• Display screen:

  15” Color LCD (TFT)

• Memory Capacity:

  16 GB

• Program Storage Capacity:

  1 GB

• Position detection system:

  Encoder

• Minimum Command Unit:

  0.0001”

• Program input system:

  EIA/ISO
