Mazak Optiplex Nexus 3015 2015

machine specifications

• Vertical Travel of Ram:

  4444

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Spindle Taper (CAT/BT):

  HSK-463

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Structure:

  Flying Optics

• Max Material Thickness (Stainless):

  0.375"

• Max Material Thickness (Mild Steel):

  0.750"

• Feedrates (X/Y/Z):

  2,362 IPM

• Power:

  2.5 KW (CO2)

• Maximum Workpiece Dimensions:

  60.04" x 120.08"

• Work Table Height:

  35.43"

• Max Thickness Aluminum:

  0.250"

• Z axis:

  Belt Drive

• Number of Control Axis:

  3

• Positioning Accuracy X, Y Axis:

  0.002 "/19.69"

• Z axis:

  0.0004 in/3.94"

• Repeatable Accuracy:

  X, Y Axis 0.001"

• Total Electrical Requirement:

  51 kVA

• Total Electrical Requirement::

  kVA

• Installation Dims W x D:

  330"x 170"

• Machine Unit Dims W x D x H:

  119.5" x 392.1" x 95.3"

• CPU:

  64 bit

• Display screen:

  Touch Panel

• Memory Capacity:

  16 GB

• Minimum Command Unit:

  0.0001"

• Position detection system:

  Encoder
