Mitsubishi ML3122 VZ10 2013

machine specifications

• Wire Traveling Speed:

  22

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Chuck Size (Inches):

  8"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• X - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Feedrates (X/Y/Z):

  1378"/min

• Resonator ( Type ):

  55

• Stroke (W,U) [o]:

  (W) +/- 360 (U) +/- 180

• Motion Drive System:

  Precision ball screw

• Machine Structure Z:

  Precision Rack & Pinion

• Travel Drive Method:

  X, Y, Z, W, U Simultaneous 5-axis

• Table Pass Height:

  25.6"

• H-axis stroke:

  +/-0.39

• Rapid travel speed [X,Y,Z]:

  1378"/min 2D program

• Rapid travel speed (W, U or A,C):

  360 °/sec

• Repeatability [X,Y,Z]:

  +/- 0.00059

• Drive Motor Type:

  AC Servo

• Max. Workpiece Weight:

  4400 lb

• CPU:

  64-bit

• Display screen:

  15" TFT color LCD touch screen

• Hard disk:

  20 GB

• Position detection system:

  Encoder
