Heat Exchanger Standard, 8 dielectric filters paper cartridges, ISPG Generator, 15 inch LCD Touch screen Display
Make: Charmilles
Model: Form 400
Year: 2014
Control: - New HMI Diesinker
Type: Sinker EDM
Reference: 3340283
-
Y-Axis Travel 27.6"
-
Chuck Size (Inches) 8"
-
X - Axis Travel (inches) 15.7" / 400mm
-
Y - Axis Travel (inches) 15.7" / 400mm
-
Z - Axis Travel (inches) 14.7" / 375mm
-
Spindle Taper (CAT/BT) HSK-463
-
Spindle Speed 12,000 RPM
-
Max Swing (inches) 17.32"
-
Bar Stock Capacity 2.0"
-
Pallet Size (inches) 25"
-
Table Size - L 61"
-
Table Size - W 30"
-
Throat Depth 9.45"
-
Turret Capacity 8 Positions
-
V-Axis Travel 5555
-
Vertical Travel of Ram 4444
-
Wire Diameter (inches) 3333
-
Wire Traveling Speed 22
-
Resonator ( Type ) 55
-
Traverse Speed Z 24.6 ft/min
-
Traverse Speed X/Y 19.7 ft/min. (Selectable)
-
Table Size 43.31" x 35.43" (X,Z)
-
Z-Axis Travel 43.5"
-
X-Axis Travel 14.3"
-
Tool Changer Type 60 ATC
-
X/Y/Z Axes Display Resolution 0.00002"
-
Permissible Workpiece Weight 6800 lbs
-
Internal Tank Dimensions (W x D x H) 71.42" x 47.83" x 27.56"
-
Programmable Tank Level 0" - 25.59"
-
Distance Table to Quill min/max 12.68" - 32.36"
-
Accura C-axis rotation speed 0 - 100 RPM
-
Max. Current Load for Accura C-Axis Static 140 amps/rotating 80 amps
-
Maximum Flushing Pressure C-axis 1.5 Bar
-
Chuck 110/220 lbs
-
Max. Allowable Tool Weight for toolchanger 22 lbs per tool change position
-
Dielectric Capacity 662.5 gallons
-
Peak Amperage 80 amps (140 optional)
-
Surface Finish Down to 5 ?inch Aa (0.1 Ra ?m)
- Additional power module to increase amperage to 140A
- Additional 10 position linear tool changer added to the right of the tank
- Drop shutter for smoke extraction duct.
- 3R-656.31-5P Measuring sensor with 5mm ball
- Marco tooling
- No white layer surface Integrity
- Pressure switch automatically shuts down machine upon system activation.
- High tech polymer tubing which will rupture when exposed to temperatures over 212 degrees F (100 C) and react quickly.
- Linear detector pressurized system senses heat along its entire length.
- Chrome-plated discharge nozzle(s).
- No external power required.
- System complies with NFPA 12 and is UL listed.
NOTE: In all cases of non-supervised machining (either unmanned,
overnight or over the weekend)
Customers must purchase and regularly maintain a UL approved fire extinguisher system.
*M1-2A-CH-460
A chiller is required for operation of the machine. (The chiller used should meet the following specifications.)
Cooling capacity 22,000 BTU/hr
Input voltage (3 phase) 460 VAC
