Citizen L-12 VII 2014

machine specifications

• Spindle Speed:

  12,000 RPM

• Maximum Machining Diameter:

  0.47"

• Maximum Machining Length:

  GB Machine 5.3"/ Chuck

• Maximum Machining Length:

  GBL Machine 1.1/ Chuck

• Maximum Drilling Diameter for Main Spindle:

  0.31"

• Maximum Tapping Diameter for Main Spindle (Tap, Die):

  M6

• Main Spindle Through-Hole Diameter:

  .78"

• Maximum drilling diameter for gang rotary tool:

  .19"

• Maximum tapping diameter for gang rotary tool:

  M4

• Gang rotary tool spindle speed:

  10,000min-1

• Maximum chuck diameter of back spindle:

  .47"

• Maximum protrusion length of the back spindle workpiece:

  1.18"

• Maximum drilling diameter in back machining process:

  .23"

• Maximum tapping diameter in back machining process:

  M5

• Back Spindle Speed:

  10,000min-1

• Number of tools to be mounted:

  Max.27

• Tool Size:

  Turning Tool: .39"

• Tool Size:

  Sleeve: .75"

• Rapid feed rate/All axis:

  1.37" IPM

• Motors for Spindle Drive:

  2.2/3.7 kW

• Motors for Tool Spindle Drive:

  0.75 kW

• Motors for Cutting Coolant Oil:

  0.25 kW

• Motors for back spindle drive:

  0.4/0.75kW

• Input power capacity:

  8kVA

• Center Height:

  39"

• Weight:

  3747 lbs

• For rotary tool drive of Back tool post:

  0.5kW

• Maximum drilling diameter for back tool post rotary tool:

  .19"

• Maximum tapping diameter for back tool post rotary tool:

  M4

• Rotary tool spindle speed of back tool post:

  9,000min-1
