Walter R 2004

machine specifications

• X Axis Travel:

  19.30"

• Y Axis Travel:

  12.6"

• Z Axis Travel:

  26.0"

• C axis:

  +/- 200° Rotary Table Swiveling Range

• Max Workpiece Diameter:

  12.6"

• Work Head Spindle:

  ISO 50

• Grinding Spindle Speed:

  0 to 10,000 RPM

• Power Requirement:

  25KVA, 460 v, 60hz

• Max. Length of Workpiece for Face Grinding:

  12.6"

• Max. Length of Workpiece for Contour Grinding:

  13.65"

• Precision in Linear Resolution:

  0.000004"

• Precision in Radial Resolution:

  0.0001 degree

• Max. Diameter Wheel:

  6.0"

• Peak Performance Grinding Spindle:

  20 KW / 25 HP
