Walter Helitronic Diamond 2006

machine specifications

• Control:

  HMC 600

• Longitudinal traverse (x-axis): :

  18.5"

• Vertical traverse (y-axis)::

  12.6"

• Cross traverse (z-axis): :

  25.98"

• Rotary table swivelling range (C-axis): :

  +/- 200°

• Centre height (with/without worktable): :

  5.7" / 7.48"

• Max. diameter of workpiece: :

  12.6"

• Max length of workpiece peripheral grinding:

  13.78"

• Max workpiece length face grinding: :

  11.02"

• Peak performance::

  11.5kw

• GRINDING WHEEL SPEED::

  0 - 9.500 rpm

• Connected load: :

  25 kW (400 V / 50 Hz)

• Grinding spindle speed::

  0 - 9500 rpm

• Weight:

  4600kg

• dimensions w x d x h =:

  636" x 360" x 356"
